Default Tyk Gateway Metrics Reference

Availability

Component	Version	Edition
Tyk Gateway	Available since v5.13.0	Community & Enterprise

Default Gateway Metrics

When opentelemetry.metrics.enabled is set to true, Tyk Gateway automatically exports three groups of metrics, no additional configuration required:

Request metrics: Rate, Errors, and Duration (RED) for every API request
Go runtime metrics: Memory, goroutines, and GC health
Configuration state metrics: API/policy load counts and reload events

All metrics are exported as OpenTelemetry-semantic-convention-compliant instruments and include resource attributes that identify the gateway instance.

Request Metrics

These four instruments cover the standard RED signals for every API proxied by the Gateway.

Metric Name	Type	Unit	Description
`http.server.request.duration`	Histogram	seconds	End-to-end request latency (client to Gateway to upstream and back).
`tyk.gateway.request.duration`	Histogram	seconds	Time spent inside the gateway only (middleware processing, routing). Excludes upstream response time.
`tyk.upstream.request.duration`	Histogram	seconds	Time spent waiting for the upstream service to respond.
`tyk.api.requests.total`	Counter	requests	Total number of requests processed.

The three-way latency breakdown is particularly useful for distinguishing gateway processing overhead from upstream service slowness.

Default Dimensions

Default dimensions vary by instrument:

Instrument	`http.request.method`	`http.response.status_code`	`tyk.api.id`	`tyk.response_flag`
`http.server.request.duration`	Yes	Yes	Yes	Yes
`tyk.gateway.request.duration`	Yes	-	Yes	Yes
`tyk.upstream.request.duration`	Yes	-	Yes	Yes
`tyk.api.requests.total`	Yes	Yes	Yes	-

Dimension	Description
`http.request.method`	HTTP request method (`GET`, `POST`, etc.).
`tyk.api.id`	The Tyk API ID.
`http.response.status_code`	HTTP response status code (`200`, `404`, `500`, etc.).
`tyk.response_flag`	Tyk 3-letter error classification code (e.g., `AKI`, `URS`, `CBO`), or the HTTP status code string (e.g., `"200"`) for successful requests or when error classification is absent. See the full list of response flags.

You can add more dimensions to any instrument using custom metrics.

Go Runtime Metrics

These metrics are exported automatically and reflect the health of the Go runtime inside the Gateway process. They can be disabled by setting runtime_metrics: false in the metrics config.

Metric Name	Type	Unit	Description
`go.memory.used`	Gauge	bytes	Current heap memory in use.
`go.memory.limit`	Gauge	bytes	Soft memory limit set via `GOMEMLIMIT`.
`go.memory.allocated`	Gauge	bytes	Total bytes allocated to the heap.
`go.memory.allocations`	Counter	bytes	Cumulative bytes allocated since startup.
`go.memory.gc.goal`	Gauge	bytes	Target heap size for the next GC cycle.
`go.goroutine.count`	Gauge	goroutines	Number of active goroutines. Useful for detecting goroutine leaks.
`go.processor.limit`	Gauge	threads	Number of OS threads available (`GOMAXPROCS`).
`go.config.gogc`	Gauge	percent	GC target percentage (`GOGC` env var).

Configuration State Metrics

These metrics reflect the operational state of the Gateway’s loaded configuration. They are useful for detecting silent configuration failures, for example, alerting when the number of loaded APIs drops unexpectedly.

Metric Name	Type	Unit	Description
`tyk.gateway.apis.loaded`	Gauge	APIs	Number of API definitions currently loaded and active.
`tyk.gateway.policies.loaded`	Gauge	policies	Number of policies currently loaded and active.
`tyk.gateway.config.reload.total`	Counter	reloads	Cumulative number of configuration reload events since startup.
`tyk.gateway.config.reload.duration`	Histogram	seconds	Time taken to complete each configuration reload cycle.

Resource Attributes

Every metric exported from a Gateway instance carries resource attributes, metadata that identifies the source. These are set once at startup and attached to all metrics.

Tyk-Specific Resource Attributes

Attribute	Always Present	Example	Description
`tyk.gw.id`	Yes	`gw-prod-eu-west-1-a`	Unique Gateway ID.
`tyk.gw.dataplane`	Yes	`true`	Whether the Gateway is running in a distributed Data Plane
`tyk.gw.group.id`	No	`prod-eu-west-1`	Present only for Data Plane Gateways, identifies the group.
`tyk.gw.tags`	No	`["region:eu", "env:prod"]`	Present only when the Gateway has segment tags configured.

Standard OTel Resource Attributes

Category	Attributes
Service	`service.name`, `service.version`, `service.instance.id`
Host	`host.name`, `host.arch`, `host.ip`
Process	`process.pid`

Using Resource Attributes in Prometheus

When using an OTel Collector to export to Prometheus, enable resource_to_telemetry_conversion to expose resource attributes as metric labels:

exporters:
  prometheus:
    endpoint: "0.0.0.0:8889"
    resource_to_telemetry_conversion:
      enabled: true

Alternatively, add a transform processor to metrics pipeline for OTLP exporters:

processors:
  transform/tyk_gw_resource_attrs:
    error_mode: ignore
    metric_statements:
      - context: datapoint
        statements:
          - set(attributes["tyk_gw_group_id"], resource.attributes["tyk.gw.group.id"]) where resource.attributes["tyk.gw.group.id"] != nil
          - set(attributes["tyk_gw_id"], resource.attributes["tyk.gw.id"]) where resource.attributes["tyk.gw.id"] != nil
          - set(attributes["tyk_gw_tags"], resource.attributes["tyk.gw.tags"]) where resource.attributes["tyk.gw.tags"] != nil
          - set(attributes["tyk_gw_dataplane"], resource.attributes["tyk.gw.dataplane"]) where resource.attributes["tyk.gw.dataplane"] != nil

This allows PromQL queries like:

# All metrics from a specific gateway node
{tyk_gw_id="gw-prod-eu-west-1-a"}

# Compare request rates across gateways in an edge group
sum by (tyk_gw_id) (
  rate(tyk_api_requests_total{tyk_gw_group_id="edge-eu-west"}[5m])
)

Without this setting, resource attributes are available via the target_info metric and can be joined in PromQL.

Exemplars

Exemplars are sample observations attached to histogram metric data points that carry the active trace context (specifically the trace_id and span_id of the request that produced the measurement). They create a direct, clickable link from an aggregated metric to the specific trace that caused an anomaly.

How they work in Tyk

When OpenTelemetry tracing is enabled and a histogram metric (such as http.server.request.duration) is recorded during an active sampled request, the OTel Go SDK automatically attaches the current trace and span IDs to the observation. Exemplars are only attached for sampled requests.

Infrastructure requirements

Exemplar storage and rendering must be enabled in your observability stack; nothing additional is needed on the Tyk side. For example, in the following standard OTel pipeline:

Tyk Gateway
  └─ OTLP/gRPC ──► OTel Collector ──► Prometheus ──► Grafana
                                       (exemplar storage)   (exemplar markers)

Component	Requirement
OTel Collector	Any version supporting OTLP metrics with exemplar passthrough
Prometheus	v2.26+. Start with `--enable-feature=exemplar-storage`
Grafana	v7.4+. Enable “Exemplars” toggle on the Prometheus data source

Querying exemplars in Prometheus

Exemplars are accessible via the Prometheus exemplar API:

GET /api/v1/query_exemplars?query=http_server_request_duration_seconds&start=<start>&end=<end>

Grafana workflow

When exemplar rendering is enabled, Grafana displays scatter plot markers on histogram panels. Clicking a marker navigates directly to the linked trace in your configured tracing backend (Jaeger, Grafana Tempo, etc.), with no manual trace ID lookup required.
