Quick Start with Helm Chart and PostgreSQL

The following guides provide instructions to install Redis, PostgreSQL, and Tyk stack with default configurations. It is intended for quick start only. For production, you should install and configure Redis and PostgreSQL separately.

Prerequisites

• Kubernetes 1.19+
• Helm 3+

Quick Start with PostgreSQL

The following quick start guide explains how to use the Tyk Stack Helm chart to configure a Dashboard that includes:

• Redis for key storage
• PostgreSQL for app config
• Tyk Pump to send analytics to PostgreSQL. It also opens a metrics endpoint where Prometheus (if available) can scrape from.

At the end of this quickstart Tyk Dashboard should be accessible through service dashboard-svc-tyk-tyk-dashboard at port 3000. You can login to Dashboard using the admin email and password to start managing APIs. Tyk Gateway will be accessible through service gateway-svc-tyk-tyk-gateway.tyk.svc at port 8080.

1. Setup required credentials

First, you need to provide Tyk license, admin email and password, and API keys. We recommend to store them in secrets.

NAMESPACE=tyk
REDIS_BITNAMI_CHART_VERSION=19.0.2
POSTGRES_BITNAMI_CHART_VERSION=12.12.10

API_SECRET=changeit
ADMIN_KEY=changeit
TYK_LICENSE=changeit
ADMIN_EMAIL=[email protected]
ADMIN_PASSWORD=changeit

kubectl create namespace $NAMESPACE

kubectl create secret generic my-secrets -n $NAMESPACE \
    --from-literal=APISecret=$API_SECRET \
    --from-literal=AdminSecret=$ADMIN_KEY \
    --from-literal=DashLicense=$TYK_LICENSE

kubectl create secret generic admin-secrets -n $NAMESPACE \
    --from-literal=adminUserFirstName=Admin \
    --from-literal=adminUserLastName=User \
    --from-literal=adminUserEmail=$ADMIN_EMAIL \
    --from-literal=adminUserPassword=$ADMIN_PASSWORD

2. Install Redis (if you don’t already have Redis installed)

If you do not already have Redis installed, you may use these charts provided by Bitnami.

helm upgrade tyk-redis oci://registry-1.docker.io/bitnamicharts/redis -n $NAMESPACE --install --version $REDIS_BITNAMI_CHART_VERSION

Follow the notes from the installation output to get connection details and password. The DNS name of your Redis as set by Bitnami is tyk-redis-master.tyk.svc:6379 (Tyk needs the name including the port)

The Bitnami chart also creates a secret tyk-redis which stores the connection password in redis-password. We will make use of this secret in installation later.

3. Install PostgreSQL (if you don’t already have PostgreSQL installed)

If you do not already have PostgreSQL installed, you may use these charts provided by Bitnami.

helm upgrade tyk-postgres oci://registry-1.docker.io/bitnamicharts/postgresql --set "auth.database=tyk_analytics" -n $NAMESPACE --install --version $POSTGRES_BITNAMI_CHART_VERSION

Follow the notes from the installation output to get connection details.

We require the PostgreSQL connection string for Tyk installation. This can be stored in a secret and will be used in installation later.

POSTGRESQLURL=host=tyk-postgres-postgresql.$NAMESPACE.svc\ port=5432\ user=postgres\ password=$(kubectl get secret --namespace $NAMESPACE tyk-postgres-postgresql -o jsonpath="{.data.postgres-password}" | base64 -d)\ database=tyk_analytics\ sslmode=disable

kubectl create secret generic postgres-secrets  -n $NAMESPACE --from-literal=postgresUrl="$POSTGRESQLURL"

4. Install Tyk

helm repo add tyk-helm https://helm.tyk.io/public/helm/charts/

helm repo update

helm upgrade tyk tyk-helm/tyk-stack -n $NAMESPACE \
  --install \
  --set global.adminUser.useSecretName=admin-secrets \
  --set global.secrets.useSecretName=my-secrets \
  --set global.redis.addrs="{tyk-redis-master.$NAMESPACE.svc:6379}" \
  --set global.redis.passSecret.name=tyk-redis \
  --set global.redis.passSecret.keyName=redis-password \
  --set global.postgres.connectionStringSecret.name=postgres-secrets \
  --set global.postgres.connectionStringSecret.keyName=postgresUrl

5. Done!

Now Tyk Dashboard should be accessible through service dashboard-svc-tyk-tyk-dashboard at port 3000. You can login to Dashboard using the admin email and password to start managing APIs. Tyk Gateway will be accessible through service gateway-svc-tyk-tyk-gateway.tyk.svc at port 8080.

You are now ready to create an API.

For the complete installation guide and configuration options, please see Tyk Stack Helm Chart.
