Export a Tyk OAS API

Last updated: 2 minutes read.

Introduction

Tyk Gateway API and Tyk Dashboard API both support exporting the entire Tyk OAS API Definition or just the OpenAPI Document part so that you can manage or work on them outside Tyk.

Note

Tyk OAS API support is currently in Early Access and some Tyk features are not yet supported. You can see the status of what is and isn’t yet supported here.

Differences between using the Tyk Dashboard API and Tyk Gateway API

The examples in these tutorials have been written assuming that you are using the Tyk Gateway API.

You can also run these steps using the Tyk Dashboard API, noting the differences summarised here:

Interface Port Endpoint Authorization Header Authorization credentials
Tyk Gateway API 8080 tyk/apis/oas x-tyk-authorization secret value set in tyk.conf
Tyk Dashboard API 3000 api/apis/oas Authorization From Dashboard User Profile
  • When using the Tyk Dashboard API, you can find your credentials key from your User Profile > Edit Profile > Tyk Dashboard API Access Credentials

Note

You will also need to have ‘admin’ or ‘api’ rights if RBAC is enabled.

Tutorial 1: Export the Tyk OAS API definition

Property Description
Resource URL /tyk/apis/oas/{API-ID}/export
Method GET
Type None
Body None
Parameters Path: API-ID

The only thing you need to do in order to get the Tyk OAS API Definition for a specific API is to call the Tyk Gateway API’s export endpoint:

curl --location --request GET 'http://{your-tyk-host}:{port}/tyk/apis/oas/{API-ID}/export' \
--header 'x-tyk-authorization: {your-secret}'

Tutorial 2: Export just the OpenAPI Document

Property Description
Resource URL /tyk/apis/oas/{API-ID}/export
Method GET
Type None
Body None
Parameters Path: API-ID Query: mode

Tyk eases the integration with other applications, such as your Developer Portal, by allowing you to export just the OpenAPI Document. It does this by stripping out the x-tyk-api-gateway configuration from the Tyk OAS API Definition.

To achieve this you simply add the mode=public query parameter to your call to the Tyk Gateway API’s export endpoint:

curl --location --request GET 'http://{your-tyk-host}:{port}/tyk/apis/oas/{API-ID}/export?mode=public' \
--header 'x-tyk-authorization: {your-secret}'
